36v 48v 8ah/14ah/16ah/20ah Battery For 200w-1500w Ebike Electric Bicycle

Product Descriptions:

We Committed to innovation, cutting-edge technology and high-quality materials, it facilitates the provision of cost-effective e-bike batteries to meet riders' various transportation needs and even their desire to explore sports and the outdoors.

Please note before buying:

1, your bicycle voltage is how much, if it is 48V to buy 48V battery, if it is 36V to buy 36V battery, you can also see from your original battery or control center can see how much voltage you need battery.

10Ah,15Ah,20Ah, 30Ah represent the battery capacity, representing the mileage

2. Whether the battery is the right size to fit into your bike frame

3. When charging, connect the power supply first and then the battery

4. Do not completely use up the battery's power, and it is better for the battery to charge every time you retain some power

The Charger is UL 62368-1 certified and can provide documentation showing certification on request.

The Battery is UL 2849 UL 2272 certified and can provide documentation showing certification on request.

The creepage distance and electrical gap distance in the charger are sufficient, the product does not pose a fire risk, will not cause components to overheat or explosion, and the output has a fuse to protect

the battery pack from overcurrent conditions.  Battery charging input and output cables are also adequately protected against stress.

The plug meets the size requirements of the relevant standards, and there is no risk of electric shock to the user.  The fuse complies with relevant standards and does not pose a risk of fire or explosion in the

event of failure.  The product has been marked and labeled in accordance with the standards

Specification:

Parameter

36V 10Ah

36V 14Ah

36V 20Ah

48V 8Ah

48V 10Ah

Nominal Voltage

36V

36V

36V

48V

48V

Nominal Capacity

10Ah

14Ah

20Ah

8Ah

10Ah

Nominal Watt Hour

360WH

504WH

720WH

384WH

480WH

Composed Type

10S4P

10S5P

10S7P

13S3P

13S4P

Built-in BMS

30A (30Amp)

30A  (30Amp)

30A (30Amp)

30A (30Amp)

30A (30Amp)

Fit Motor Power

0-1000W max

0-1000W max

0-1000W max

0-1500W max

0-1500W max

Charge Cut-off Voltage

42V

42V

42V

54.6V

54.6V

Discharge Plug

                                                       T-head (with XT60 adapter)

Battery Weight

3.15KG

3.5KG

4.5KG

2.8KG

3.2KG

Battery Charger

42V 2A

42V 2A

42V 2A

54.6V 2A

54.6V 2A

Battery Pack Cell

Domestic Grade A 18650 cells

Dimension

210*92*70mm

210*110*70mm

220*140*70mm

266*72*70mm

 268*94*70mmMax Discharge Current30A(30Amp)30A(30Amp)30A(30Amp)30A(30Amp)30A(30Amp)



Parameter

48V 14Ah

36V 16Ah

48V 20Ah

/

/

Nominal Voltage

48V

36V

48

/

/

Nominal Capacity

14Ah

16Ah

20Ah

/

/

Nominal Watt Hour

672WH

576WH

960WH

/

/

Composed Type

13S5P

13S8P

13S7P

/

/

Built-in BMS

30A (30Amp)

30A (30Amp)

30A (30Amp)

/

/

Fit Motor Power

0-1500W max

0-1000W max

0-1500W max

/

/

Charge Cut-off Voltage

54.6V

42V

54.6

/

/

Discharge PlugT-head(with XT60 adapter

//

Battery Weight

3.4KG

3.15KG

5.6KG

/

/

Battery Charger

54.6V 2A

42V 2A

54.6V 2A

/

/

Battery Pack Cell

Domestic Grade A 18650 cells

Dimension

270*107*70mm

210*120*70mm

270*140*70mm/

/

Max Discharge Current30A(30Amp)30A(30Amp)30A(30Amp)//



The Charger is UL 62368-1 certified and can provide documentation showing certification on request.

The Battery is UL 2849 UL 2272 certified and can provide documentation showing certification on request.

Specification:

 36V 10AH 100W-1000W Nominal Voltage: 36VRated Capacity: 10AhMax Constant Discharge Current:30A( BMS)

Apply for: 100W-1000W Motor eBike Electric bicycle bike

Battery Type:Lithium Ion (Li-Ion)

Size/Weight: 210*92*70mm(3.15kg) (8.3*3.6*2.8inch) Charger : 42V 2 A

Discharge: T head

Battery Cell: 18650 A Grade

Weight:2.90KG

  36V 14AH 100W-1000W Nominal Voltage: 36VRated Capacity: 14AhMax Constant Discharge Current:30A( BMS)

Apply for: 100W-1000W Motor eBike Electric bicycle bike

Battery Type:Lithium Ion (Li-Ion)

Size/Weight: 210*110*70mm(3.5kg)(8.27*4.33*2.76in)Charger : 42V 2 A

Discharge: T head

Battery Cell: 18650 A Grade

Weight:3.50KG

36V 16AH 100W-1000W



Nominal Voltage: 36VRated Capacity: 16AhMax Constant Discharge Current:30A( BMS)

Apply for: 100W-1000W Motor eBike Electric bicycle bike

Battery Type:Lithium Ion (Li-Ion)

Size/Weight: 210*120*70mm(3.15kg)(8.3*4.72*2.8inch)Charger : 42V 2 A

Discharge: T head

Battery Cell: 18650 A Grade

Weight:3.15KG

  36V 20AH 100W-1000W Nominal Voltage: 36VRated Capacity: 20AhMax Constant Discharge Current:30A( BMS)

Apply for: 100W-1000W Motor eBike Electric bicycle bike

Battery Type:Lithium Ion (Li-Ion)

Size/Weight: 220*140*70mm(4.5kg) (8.66*5.51*2.76in)Charger : 42V 2 A

Discharge: T head

Battery Cell: 18650 A Grade

Weight:4.50KG

  48V 8AH 100W-1500W Nominal Voltage: 48VRated Capacity: 8AhMax Constant Discharge Current:30A( BMS)

Apply for: 100W-1500W Motor eBike Electric bicycle bike

Battery Type:Lithium Ion (Li-Ion)

Size/Weight: 266*72*70mm(2.8kg) (10.5*2.8*2.8inch)Charger : 54.6V 2 A

Discharge: T head

Battery Cell: 18650 A Grade

Weight:2.8KG

  48V 10AH 100W-1500W Nominal Voltage: 48VRated Capacity: 10AhMax Constant Discharge Current:30A( BMS)

Apply for: 100W-1500W Motor eBike Electric bicycle bike

Battery Type:Lithium Ion (Li-Ion)

Size/Weight:  268*94*70mm(3.2kg) (10.6*3.7*2.8inch)Charger : 54.6V 2 A

Discharge: T head

Battery Cell: 18650 A Grade

Weight:3.2KG

  48V 14AH 100W-1500W Nominal Voltage: 48VRated Capacity: 14AhMax Constant Discharge Current:30A( BMS)

Apply for: 100W-1500W Motor eBike Electric bicycle bike

Battery Type:Lithium Ion (Li-Ion)

Size/Weight: 270*107*70mm(3.4kg) (10.6*4.21*2.8inch)Charger : 54.6V 2 A

Discharge: T head

Battery Cell: 18650 A Grade

Weight:4.20KG

48V 20AH 100W-1500W



Nominal Voltage: 48VRated Capacity: 20AhMax Constant Discharge Current:30A( BMS)

Apply for: 100W-1500W Motor eBike Electric bicycle bike

Battery Type:Lithium Ion (Li-Ion)

Size/Weight: 270*140*70mm(5.6kg) (10.63*5.51*2.76in)Charger : 54.6V 2 A

Discharge: T head

Battery Cell: 18650 A Grade

Weight:5.60KG

Package List : 1 x 36V / 48V Lithium ion Battery1 x 2A / 5A Fast Charger or Without Charger (optional1 x T Plug / Anderson Plug1 x T to XT60 Female Plug / Anderson Female Plug
